Diana 2 (scale 1/3)

Diana 2 (scale 1/3)
Referral code: scl-001

Diana 2 is a scale model at a rate of 1/3 of the very popular glider.

It has been designed for GPS-triangle competition with the latest technology for aerodynamic performance and for structural stiffness and strength. With 100% molded technology.

Of course it can be used for hobby slope and thermal flying.

The performance of the model in flying conditions is very high, with a profile based in the f3b concept, you will be able to fly slow in thermals, fast in speed and at a good glide ratio for distance flying, so you will be able to be competitive in GPS-triangle. It is easy to handle in circling and very gentle for approach and landing.

It is recommended for pilots that want to entry GPS-triangle competition and don't want to spend too much money for a 7m glider.

This model shares the wings with our DNAracer GPS-triangle Sport Class glider, you just need to order the fuselage, elevator, joiners and wing tips to have two high performance gliders.

 Model information
3s View
CategoryGps-Triangle
DesignBaudis Jiri
AirfoilPflug Dirk
Wingspan5000 mm
Length2330 mm
Wing Area103 dm2
Aspect Ratio24.8
Weight6500 - 11000 gr

Approximate flying weights Diana 2 (scale 1/3) as follows:

With motor and with retractable landing gear:

  • Standard                ... 10000g
  • Strong                    ... 10400g
  • Sport (GPS Light)  ...   9000g
  • GPS Spreadtow    ...    8800g

Without motor and with retractable landing gear:

  • Standard                ...   9500g
  • Strong                    ... 10000g
  • Sport (GPS Light)  ...   8300g
  • GPS Spreadtow     ...   8100g

Without motor and without retractable landing gear:

  • Standard                ... 9050g
  • Strong                    ... 9550g
  • Sport (GPS Light)  ... 7850g
  • GPS Spreadtow     ... 7650g

*These are approximate flying weights. Depends on used components (servos, motor), way of building, etc.

*It is estimation of the final weight based on our best experience.
